12mm Planetary gearbox

Quantity:
  • P121
Gearbox Description
Housing
material
Bearing
at output
Radial load
(5mm from flange)
Shaft
axial load
Shaft press fit
force,max.
Radial play
of shaft
Thrust play
of shaft
Backlash
 at no-load
MetalSleeve bearings≤0.5Kgf≤0.5Kgf≤1.5Kgf≤0.05mm≤0.2mm≤3°


Motor Shaft Pinion Specification
ModuleNo. of teethPressure angleHole diameterReduction ratio.
0.251220°1.49


Gearbox Specification
Reduction
ratio
Rated  tolerance
torque(Kg.cm Max.)
Max momentary
tolerance torque(Kg.cm )
EfficiencyLength
(L-mm)
Weight(g)
Sleeve  bearings
1/40.82.485%12.812.1
1/161.23.675%16.114.2
1/641.64.865%19.416.3
1/2561.85.455%22.718.4
1/10242645%2620.5
1/40962640%29.322.6


                                                                Mechanical Dimensions
1


Full Datasheet

D123.doc
