22mm DC Planetary Gearmotor 12V

• Manufacturer Part Number: DP223C
• Gearbox Type: Planetary Geared box with Metal Gear
• Gear Ratio:1:5~1:3968
• Electric Planetary Reducer Size: 22mm
• Ball bearing of shaft bearings in most series is available
• OEM Custom modifications is available.
• Application: Automatic Window Bind Motor,
Medical Instrument Motor

Quantity:
  • DP223C GearMotor 12V
  • I.CH
  • 22mm Reducer Motor

The Specification in the table comes from the motor with planetary gearbox, planetar gears is all Metal Gear, highest torque is 25kg.cm

Gear Motor Torque & Speed

Reduction ratio1/51/181/201/251/661/771/901/1101/1361/2461/3361/3931/4841/5971/7351/10791/14751/21241/3968
12VRated
torqu(g.cm)
8027031038085010001150140017002600370042005000500050006000600060006000
Rated speed(rpm)14003753252601018674604826191613.811.59.56.753.41.8
24VRated
torqu(g.cm)
8027031038085010001150140017002600370042005000500050006000600060006000
Rated
speed(rpm)
15504143552901109582665329211815.312.710.57.45.53.91.95

Rotation
direction
CCW

Length
(L-mm)
23.329.535.741.948.1

• Different material or different spec of gears can be customized chosen, all plastic, all metal, or helical gears versions.

• Modified versions for extended temperature and special environmental conditions are available.


DC Motor Specification
Rated volt
(V)
Rated torque
(g.cm)
Rated speed
(rpm)
Rated current
(mA)
No load speed
(rpm)
No load current
(mA)
Weight(g)
12 22 6700 <=200 8000 <=70 32
24 22 7400 <=110 9000 <=40 32

D223C-01&02电机曲线

                                                          Mechanical Dimensions
D223C-01&02



Full Datasheet

D133-01&02.doc
