32mm DC Planetary Gearmotor

• Manufacturer Part Number: DP321 with small motor
• Gearbox Type: Planetary Geared box with Mixed Gear
• Gear Ratio:1:5~1:721
• Electric Planetary Reducer Size: 32mm
• Ball bearing of shaft bearings in most series is available.
• OEM Custom modifications is available.
• Application: Cosmetology Instrument Motor, IT Mechanism Motor

Quantity:
  • DP321 GearMotor 12V
  • I.CH
  • 32mm Reducer Motor

The Specification in the table comes from the motor with planetary gearbox, planetar gears is different material gear, highest torque is 12kg.cm

Gear Motor Torque & Speed

Reduction
ratio
1/51/141/191/271/351/511/711/1001/1391/1891/2641/5161/7211/939
12VRated
torque(Kg.cm)
0.30.7511.41.92.33.34.66.57.310121212
Rated
speed(rpm)
995373270195150104745338282011.28.36.3
24VRated
torque(Kg.cm)
0.30.711.41.82.23.14.46.16.99.7121212
Rated
speed(rpm)
990370265191150103745338282011.28.36.3

Rotation
direction
CCW

Length
(L-mm)
20.62733.439.8


• Different material or different spec of gears can be customized chosen, all plastic, all metal, or helical gears versions.

• Modified versions for extended temperature and special environmental conditions are available.


DC Motor Specification
Rated volt(V) Rated torque
(g.cm)
Rated speed
(rpm)
Rated current
(mA)
No load speed
(rpm)
No load current
(mA)
Weight(g)
12 78 5290 <=530 6500 <=150 73
24 74 5250 <=250 6500 <=85 73

D323-01&02电机曲线

                                                        Mechanical Dimensions
D323-01&02




Full Datasheet

D323-01&02.doc
