36mm DC Planetary Gear Motor

• Manufacturer Part Number: D363-1:27
• Gearbox Type: Planetary Gearbox
• Gear Ratio:1:27
• Micro Planetary Gear Motor Size: 36mm
• Application: Bank ATM Motor

Quantity:
  • D363-1:27(36mm)
  • I.CH

37mm Planetary Gear Reduction integrated a 36mm planetary gearbox of 1:27 gear ratio. It is a good solution to application that with limited space but low speed and high torque.
Electrical Specification
Voltage
(V)
No load speed
(rpm)
Noroad current
(A)
Rated torsion
(Kg.cm)
Raterd speed
(rpm)
Raterd current
(A)
Max. Torque
( Kg.cm )
Ratio
24 130 0.15 10 95 0.7 15 1:27
Note: Product voltage, output shaft size, electrical performance, you can request custom-made!

Encoder

111

Clutch



Connector
Molex,Harwin,Tyco/AMP,JST etc.
QQ截图20180621113414

Motor
Brush Motor,Brushless Motor,Stepper Motor
Shaft
D-cut Shaft,H-cut Sahft,Rround Sahft

Mechanical Dimensions
尺寸图

MOTOR CHARACTERISTICS
曲线图

Full Datasheet
D363.pdf
