59mm AC Induction Synchronous Motor

• Manufacturer Part Number: S593E
• Motor Type: AC Synchronous Motor
• Speed : 0.05~3.3rpm
• Frequency: 50Hz or 60 Hz
• Power: Lower than 20W(24~220VAC)
• Torque: Max 200kg.cm
• AC Gear Motor Rotation:CW,CCW,Bi-directional
• Application: Valve Activator Drive Motor

Quantity:
  • S593E(59mm)- 50/60Hz
  • I.CH
Specification
ModelOutput speed
(rpm)
Output Torque (kg.cm)Voltage
(V.AC)
Current
(A)
Frequency
(Hz)
Input Power
(W)
Noise
(dB)
Rotation
S1 continuousS2
15 minutes
S2
5 minutes
S593-200-0050.05200    24
*********
110
*********
220
<0.9
**********
<0.2
*********
<0.1
50/60Hz<20<45CW / CCW / Bi-directional
S593-200-0080.08200
S593-200-0110.11200
S593-200-0160.16200
S593-200-0250.25200
S593-200-0330.33200
S593-200-0500.5200
S593-200-0660.66200
S593-180-0830.83180
S593-150-2002150
S593-150-3303.3150
Note:  Above datas are from motors under 50Hz. If under 60Hz, Speed*1.2 , Torque/1.2
       Other speed and torque needed, please contact our sale department


Safety
Insulation resistanceDC 500V 100M ohms
Insulation strengthAC1500V, 50Hz/min(220V motor)
Insulation classE(105) / B(130)
EnvironmentTemp.-10~+40 / Humidity:<85
Certification CE ROHS CCC


Mechanical Dimensions
S593E DWG

Custom Shaft
Round Shaft, D-Cut Sahft, H-Cut Shaft, Custom Length

AC Motor with Gearbox
QQ图片20180626145005

Cooling fan
QQ图片20180625151032

Connector
Molex, Harwin, Tyco/AMP, JST etc.

connector


Leadwires and Cables
Special lengths, Protective hose

wires
Full Datasheet
S593E.pdf

Factory Ability
I.CH Motion provides all kinds of electric motors, such as AC Geared Motor, AC Synchronous Motor, AC Induction Synchronous Motor and all motor parts. We have accumulated over ten years experience to meet different clients requires, all of our products can be customized. And we are a mature team with professional engineer, technician and sales, furthermore, we provide all customers with best after-sales service.

Advantages
1. We offer OEM service;
2. We provide you with professional technical guidance in the middle of usage;
3. Refunds or replacement in case of damaged by transportation;


Package
Cartons and pallets filled with protection film;
Vessel shipping or Courier express for sample order;;
Due: 10 - 50 days.
未标题-1  未标题-2  未标题-3


FAQ
Q: What voltage for the 59mm AC Synchronous Motor?
A: 24V, 110V, 230V or it could be customized.

Q: Where can the synchronous geared motor be used?
A: It can be used in Household Electrical Appliances Motor, such as water valve control or other valve control system.

Q: Do you have any products in stock? Can I order samples first?
A: Most of our products are customized, we do not make customs products in stock normally, the sample often takes 5-10 days.
