VIRTUAL TOUR

I.CH was found in 2006, located in Nanjing, China. We specialized in researching, developing and servicing electric motors, gearbox and high precision gears with small module. After years of development, we have an independent product design and R&D team, service team and professional quality control team. To realize our service concept better, provide high quality products and excellent service, we have been committed to the core ability and training. We have a holding factory in Nanjing, which produce high presicion? small?moulds gears, gearbox and planetary gearbox assembling.
  • I.CH Motion Co., Ltd Factory

VIDEO

Electric DC Gear Motors: Brushed Planetary Gear Motor is an electric motor that uses direct current to power itself. The motor consists of a stator, which is the stationary part of the motor, and a rotor, which is the rotating part of the motor. The stator contains an electromagnet, which creates a magnetic field. The rotor contains a set of magnets, which are attracted to the electromagnet in the stator.

This interaction between the electromagnet and the magnets in the rotor causes the rotor to rotate.Brushed motors are typically less expensive than their brushless counterparts and are often used in applications where cost is a major consideration. However, brushed motors are not as efficient as brushless motors and require more maintenance due to the brushes coming into contact with the spinning commutator.

Gear Blank Processing

Automatic gear blank machining lathe was imported from Japan. The high precision gear blank machining is the most critical process in the process of precision gear machining. As the precision benchmark of gear machining and testing, the inner hole of gear blank needs high precision, including roundness, roughness, dimensional tolerance, etc.

Small module precision gear processing

Small module precision gear processing equipment is equipped with high-precision fixture tools. By the specially customized cutting tools and process technical, it can machine gears of various materials such as engineering plastics, non-ferrous metals, alloy steel and stainless steel.

Installation of gearbox output gear

Installation of gearbox output gear assembly with overload protection function and commissioning of clutch protection torque. This relates to a torque adjusting structure of a gearbox, which relates to the field of electric tools, which comprises shaft, telescopic spring, threaded sleeve and torque cup.

Precision Gearbox Efficiency Test

The test equipment is suitable for gear reducer, especially for the comprehensive performance test of precision reducer. The reducer could be Spur gearbox and planetary gearbox. This is our self-developed testing equipment. We can design different testing equipment according to different application.

The inspection of gear rack

The inspection of gear rack mainly depends on the tooth profile, tooth pitch and flatness. The best inspection method is to use the CMM, so that all the data can be obtained intuitively. However, subject to the time and place, it can also be tested with an outer micrometer and feeler gauge.

EXPLORE MORE OF OUR PRODUCTS

Planetary gear motors are one of the most popular types of motors used in a wide range of applications. They are known for their high efficiency and reliability, and are often used in applications where space is limited.

One of the great things about planetary gear motors is that they can be customized to meet the specific needs of your application. For example, you can choose the number of gears, the gear ratio, and the size of the motor. This makes them perfect for a wide range of applications, from small electronic devices to large industrial machines.

If you're looking for a high-quality motor that can be customized to meet your specific needs, then a planetary gear motor is an excellent choice.
