500mm-2000mm Spur Gear racks
I.CH
Spur Gear racks
Key Characteristics of Gear Rack
As we all know, the longer the rack, the more difficult it is to control deformation. For the rack with a length of more than 800mm, if the straightness is to be kept within 0.1mm, the rack blank can only be achieved after several times of stress relief, and the process is relatively complex. We can also maintain the straightness through special processing methods, such as electric discharge (wire cutting), so as to avoid the cumulative error caused by gear grinding.
Gear Racks Application
- A gear rack is a straight or curved row of gear teeth that mesh with the teeth of a pinion gear.
- It is a linear or straight-toothed gear, essentially a gear cut into a straight, flat surface.
- The motion of the rack is linear (straight-line) and is typically used to translate rotary motion into linear motion or vice versa.
- Gear racks are commonly used in applications such as CNC (Computer Numerical Control) machines, linear actuators, and in some steering systems.
Gear Rack and Pinion Gears
A gear rack and pinion system is a fundamental mechanical arrangement that converts rotational motion to linear motion and vice versa. It finds widespread use in various industries due to its efficiency, precision, and versatility.
I.CH can provide one-stop automation services, including servo motor, precision gearboxes, pinions, and gear racks.
I.CH precision gearbox can pre-mounted the pinions, to match the gear rack working.
| Mod. | Hp | HexS | L | ||||||||
| 500 | 1000 | 2000 | |||||||||
| Teeth No. | Lr | Weight(kg) | Teeth NO. | Lr | Weight(kg) | Teeth NO. | Lr | Weight(kg) | |||
| 1 | 14 | 15x15 | 159 | 449.51 | 0.82 | 318 | 999.02 | 1.5 | 636 | 1998.05 | 3.1 |
| 1.5 | 15.5 | 17x17 | 106 | 449.51 | 1 | 212 | 999.02 | 2 | 424 | 1998.05 | 4 |
| 2 | 18 | 20x20 | 80 | 502.65 | 1.4 | 159 | 999.02 | 2.7 | 318 | 1998.05 | 5.4 |
