DS332
I.CH
33mm DC Gear Motor
Description
DC gear motor, namely Gear Reduction Motor, uses the gear of input shaft to mesh the gear of output shaft to achieve the goal of reducing speed. The function of the gearbox is to provide a relatively slow speed and a relatively high torque.
33mm DC Geared Motor integrated a spur gearbox of 1:10 to 1:1350 gear ratio. It is a good solution to application that with limited space but low speed and high torque.
Gearbox Specification
Number of Stages | 2 | 3 | 4 | 5 | 6 | 7 |
Reduction Ratio | 10 | 20 | 50 | 150 | 300 | 750 |
30 | 60 | 180 | 350 | 900 | ||
70 | 210 | 450 | 1050 | |||
90 | 270 | 630 | 1350 | |||
Length of Gearbox (mm) | 19.0 | 21.5 | 24.0 | 26.5 | 29.0 | 31.5 |
DC Gear Motor Specification
Model | Rated Voltage (V) | Rated Torque （kg.cm） | Rated Speed (rpm) | Rated Current (mA) | Output Power (mW) | Torque at Stall (Kg.cm) | Current at Stall (mA) | No Load Speed (rpm) | No Load Current (mA) |
D332-018050 | 24.0 | 1.8 | 145 | 220 | 3000 | 10.0 | 1000 | 180 | 50 |
D332-090490 | 24.0 | 9.0 | 11 | 100 | 1200 | 40.0 | 700 | 12 | 45 |
D332-050270 | 12.0 | 5.0 | 9 | 100 | 500 | 30.0 | 400 | 11 | 25 |
D332-018070A | 12.0 | 1.8 | 48 | 150 | 1000 | 10.0 | 600 | 60 | 50 |
D332-018070B | 12.0 | 1.8 | 80 | 320 | 1600 | 12.0 | 2000 | 96 | 100 |
D332-013030 | 12.0 | 1.3 | 230 | 600 | 3500 | 8.0 | 2600 | 280 | 100 |
D332-013050 | 6.0 | 1.3 | 125 | 850 | 1900 | 8.0 | 3500 | 152 | 170 |
D332-030090 | 12.0 | 3.0 | 48 | 320 | 2000 | 18.0 | 1500 | 60 | 50 |
D332-018050 | 24.0 | 1.8 | 100 | 150 | 2100 | 10.0 | 700 | 125 | 45 |
Description
DC gear motor, namely Gear Reduction Motor, uses the gear of input shaft to mesh the gear of output shaft to achieve the goal of reducing speed. The function of the gearbox is to provide a relatively slow speed and a relatively high torque.
33mm DC Geared Motor integrated a spur gearbox of 1:10 to 1:1350 gear ratio. It is a good solution to application that with limited space but low speed and high torque.
Gearbox Specification
Number of Stages | 2 | 3 | 4 | 5 | 6 | 7 |
Reduction Ratio | 10 | 20 | 50 | 150 | 300 | 750 |
30 | 60 | 180 | 350 | 900 | ||
70 | 210 | 450 | 1050 | |||
90 | 270 | 630 | 1350 | |||
Length of Gearbox (mm) | 19.0 | 21.5 | 24.0 | 26.5 | 29.0 | 31.5 |
