36mm DC Planetary Gearmotor

• Manufacturer Part Number: DP364P
• Gearbox Type: Planetary Geared box with Powder Metallurgy Gear
• Gear Ratio:1:5~1:721
• Electric Planetary Reducer Size: 36mm
• Ball bearing of shaft bearings in most series is available.
• OEM Custom modifications is available.
• Application: Automatic Window Bind Motor, Medical Instrument Motor
Availability:
Quantity:
  • DP364P GearMotor

  • I.CH

  • 36mm Reducer Motor

Description of 36mm DC Planetary Gearmotor

Introducing our 36mm DC Planetary Gearmotor - the perfect solution for precise equipment and machine applications. Designed with the highest level of engineering, this gearmotor is ideal for a range of industries including banking and vending systems, electric valves and robots, household appliances and office automation, auto dispensers, cleaning machines.


The Specification in the table comes from the motor with planetary gearbox, planetar gears is different material gear, highest torque is 30kg.cm

Gear Motor Torque & Speed

Reduction ratio1/51/141/191/271/511/711/1001/1391/1891/2641/5161/721
12VRated torque(Kg.cm)1.12.53.658.211.5162025253030
Rated speed(rpm)1250475340243129926647.234.825.113.29.5
24VRated torque(Kg.cm)1.12.73.85.38.712172025253030
Rated speed(rpm)1240470335240127916546.534.324.8139.4

Rotation directionCCW

Length(L-mm)33.141.850.559.2


• Different material or different spec of gears can be customized chosen, all plastic, all metal, or helical gears versions.

• Modified versions for extended temperature and special environmental conditions are available.


DC Motor Specification for 36mm gearmotor for Precise Equipment and machine

Rated
volt(V)
Rated torque
(g.cm)
Rated
speed(rpm)
Rated
current(mA)
No load
speed(rpm)
No load
current(mA)
Weight(g)
12 270 6570 <=2050 7500 <=300 222
24 285 6480 <=1050 7500 <=210 224


DC Motor Specification for 36mm gearmotor for Precise Equipment and machine






Mechanical Dimensions
D363P-01&02


Full Datasheet

DP363P-01&02.pdf
